Ground Penetrating Radar RD LMX100™ & RD LMX200™

GPR (Ground Penetrating Radar) systems enable operators to detect underground utilities, particularly non-conductive pipes, and ducts, using high-frequency Radar.  When locating underground utilities, GPR can be a valuable complement to electromagnetic cable and pipe locators.

Radiodetection's LMX100™ and LMX200™ innovative GPR systems both use ultra-wideband 250MHz, specifically chosen for effective utility locating.  Our GPR products feature internal GPS and high-resolution touch screens. For connectivity and ease of reporting, both offer onboard Wi-Fi and a USB port. Additionally, the LMX200™ allows users to create depth slices and review their locate path on-screen while on-site, and selectively enhance shallow/small, medium depth/size, or deep/large targets using the proprietary DynaQ™ technology.


LMX100 has the advantage of detecting:

  • Metallic and non-metallic utilities
  • Utilities with broken tracer wires
  • Undocumented utilities
  • Trenches and disturbed soil, are often associated with utility burial
  • Unexpected obstacles or buried structures such as old foundations that can cause problems for excavations or construction


The LMX200™ provides unprecedented insights and target confidence to detect traditionally non-locatable subsurface features such as:

  • Non-metallic pipes, including PVC and asbestos cement
  • Underground Electrical Cable
  • Concrete storm and sewer systems
  • Utilities where installed tracer wiring has failed
  • Underground storage tanks and drainage tiles
  • Septic system components
  • Non-utility structures such as vaults, foundation walls, and concrete pads.


Learn More »

Applications Ground Penetrating Radar
Industries Civil Infrastructure, Commercial Services, Defence & Security, Education & Research, Mining, Oil & Gas, Utilities - Electricity and Water
  • USB port
  • Produce and share instant on-site reports
  • High visibility touch screen
  • Lightweight build.


Key Features for LMX100 :

  • Lead-acid gel battery
  • GPR Sensor.


Key Features for LMX200 :

  • Optional external GPS
  • Enhanced on-site capabilities.


Ground Penetrating Radar RD LMX100™ & RD LMX200™
Product Brochures

  1. lmx_brochure_eng_0 (1).pdf
